玉柴建立了包括产品销售、应用开发、售后服务、配件专卖于一体的营销管理体系,拥有行业内网络规模大、服务网点多、服务半径小、三包里程长、响应时间短的营销服务网络;建立了28个国内办事处、12个国外办事处、12个通机经理部、12个船电大区、148家海外服务代理商、3000多个服务站、5000多家配件销售网点,向海内外用户提供“捷·诚”服务。
Guangxi Yuchai Machinery Group Co., Ltd. was founded in 1951 and is headquartered in Yulin City, Guangxi. It is a large state-owned enterprise group that focuses on power systems and implements concentric and diversified development. The company has more than 20 wholly-owned, controlling, and joint-stock secondary subsidiaries with 13000 employees. Yuchai is a comprehensive and complete internal combustion engine manufacturing base in China, with a wide range of applications, achieving full coverage of low, medium, and high speeds, as well as light, medium, heavy, and large engines. It is a benchmark in the engine emission technology industry. There are industrial base layouts in Guangxi, Guangdong, Jiangsu, Anhui, Shandong, Hubei, Chongqing, Liaoning and other places, with engine sales ranking among the top in the industry for consecutive years.
Yuchai has established a marketing management system that integrates product sales, application development, after-sales service, and parts monopoly. It has a marketing service network with a large network scale, multiple service outlets, small service radius, long three guarantee mileage, and short response time in the industry; We have established 28 domestic offices, 12 foreign offices, 12 communication management departments, 12 major shipbuilding areas, 148 overseas service agents, over 3000 service stations, and more than 5000 accessory sales outlets to provide "Jie · Cheng" services to users at home and abroad.

| 机组 Generator | 品牌brand | 玉柴船电 Yuchai |
| 型号model | YC18GFS-3 | |
| 频率(Hz) | 50Hz | |
| 转速(rpm) | 3000rpm/min | |
| 电压AC(V) | 230/400 | |
| 额定电流AC(V) | 65.2/26.1 | |
| 额定功率 rated power/kW | 18 | |
| 最大功率 max power/kW | 20 | |
| 功率因素ΦCOS | 1/(0.8) | |
| 相数phase | 单相/三相 single phase/three phase | |
| 励磁方式 exciting mode | 有刷自励恒压(带AVR)Brush self-excited constant voltage (with AVR) | |
| 类型type | 静音式 Silent style | |
| 油箱容积(L) fuel tank capacity | 26L | |
| 综合运行时间(hr) Combined running time | 6h | |
| 噪音(Dba@7m) noise | <75dB | |
| 净重/毛重(KG) Gross Weight | 385/415 | |
| 机组尺寸(mm)Size | 1250×650×770 | |
| 包装尺寸(mm) package size | 1330×730×925 | |
| 是否带轮子 With or without wheels | 标配/Standard | |
| 动力 Engine | 动力型号 Engine Model | YC2V105 |
| 启动方式 start mode | 电启动 Electric start | |
| 动力类型/ Engine type | 双缸、四冲程,风冷,柴油引擎 Two-cylinder, four stroke, air cooled, diesel engine | |
| 缸径x行程(mm) Bore × Stroke | 105*88 | |
| 排量(CC) Displacement | 1523CC | |
| 压缩比 Compression ratio | 20:1 | |
| 额定功率 rated power(KW/rpm) | 22.8/3000 | |
| 机油加注量(L) Oil capacity | 3.5 | |
| 燃油类型 Fuel type | 0#(夏天),-10#(冬天),-35#(极寒)柴油 0#(summer),-10#(winter),-35#(extreme cold) diesel | |
| 润滑油类型 Lub. Type | CF20W-50(CD级以上) (Above CF grade) |

产品订购:玉柴18KW风冷柴油发电机组,配备AVR自动调压及过载保护,数据中心及银行机房应急备用
